Robotics Solar Station
ISBP4 is an advanced unit that does not require any power to run a Robotic Lawnmover. The unit is intended to be used were there is no electricity like round-abouts, summer cottages, fotball fields, islands et c.
ISBP4 does not require any connection to the powergrid , its battery bank is charged via solarpanels. The main unit has a 100 Ah LiFePO4 rechargeble
battery (max battery is 200Ah).
ISBP4 is delivered with a main unit, one battery 100 Ah, cables and solar panels. Minimum delivery is only solar panels and 100 Ah battery. ISPB 4 handle large areas such as parks, golfcourse, football field and more.
Aluminum frame is included for the solar panels.
We also have a smaller unit ISPB5 that has a smaller panel , this unit handle roundabouts or similar smaller areas up to 100 square metres. The ISBP5 comes with a foldaböle bracket to fit easily in your car.
Use our ISBP4 for larger areas and our ISBP5 for smaller areas such as roundabouts or similar.
Bracket - also available for permanent mounting.
ISPB4 and ISPB5 is available for following robots:
* Honda Miimo
* Stiga Stig A-models
* Husqvarna automover
* Wiper models
* Other on request

Features ISPB4 and ISPB5
- Battery type: LiFePO4
- Capacity: 100 Ah (or 200 Ah)
- Max running cycles: 18 h to 24 h (ISPB5 max 100 sqm)
- Control box dimensions (LxDxW): 500 x 250x 450 mm
- Protectionsclass: IP64
- Weight: 7kg
- In the box: 1 pc main unit and battery 100Ah (or 200Ah) (including unit for charger controll and battery protection), cables between units, 1 pc solar panels including frame
- Typeffekt: 1x550W or 2x550W (Ispb5 1x135W)
- ISPB5 has foldable brackets.
- Voltage (1 panel): 44 V (ISPB5 21 V)
- Panel dimensions: LxWxH: 220 x 113 x 4 cm (ISPB5 110 x 50 x 4 cm)
